MD021 Plastic Wire Drawing Machine User Manual
Figure. 2-3 Physical appearance and mounting dimensions of the
MD021 inverter
Mounting
holes
Switch Operation panel
Heatsink
115 mm
68 mm
138 mm
144.5 mm
80 mm
