Inovance MD300 Series - F4 Startup;Stop Control Descriptions

Chapter 6 Parameter Description
-66-
Group F4 Start/Stop Control
Parameters
DC brake
beginning
frequency
at stop
Factory
default
value
0.00
Hz
F4-00
Setup
range
0.00Hz maximum
frequency
DC brake
waiting
time at
stop
Factory
default
value
0.0s
F4-01
Setup range
0.0s 36.0s
DC brake
current at
stop
Factory
default
value
0%
F4-02
Setup range
0.00V10.00V
DC brake
time at
stop
Factory
default
value
0.0s
F4-03
Setup range
0.0s 36.0s
DC brake beginning frequency at stop: During
the acceleration to stop, when it reaches this
frequency, the DC brake process at stop
begins.
Brake waiting time at stop: Prior to the
beginning of DC brake at stop, the inverter
stops output and starts DC brake upon this
delay. It is used to prevent the over current
fault caused by DC brake beginning when the
velocity is relatively high.
DC brake current at stop: It refers to the
added DC brake quantity. The higher this
value is, the better the DC brake effect is.
DC brake time at stop: It refers to the added
time of the DC brake quantity. When this
value is zero, it indicates there is no DC brake
process, and the inverter will stop according to
the setup decoration to stop process.
Brake use
ratio
Factory
default
value
%
F4-04
Setup range
0%100%
It is enabled for the inverter with built-in brake
unit. It can be used to adjust the brake effect
of the bake unit.
