Insignia NS-ODL3 User Manual

5
L-Shaped Computer Desk
www.insigniaproducts.com
Hardware included
Tools needed
Preparing to assemble your desk
1 Follow the assembly instructions carefully.
2 Make sure that all parts and hardware are included.
3 To prevent product damage, assemble your desk on top of the box.
4 Have another person help you with lifting and assembly.
5 For the best results, do not fully tighten the screws until you have assembled all the other parts.
CAUTION: Do not use a drill to assemble your desk. The drill should only be used to secure your desk to the wall (step 18).
LABEL HARDWARE QTY.
A26
B19
C19
D3
E13
F13
G16
Wooden dowels
Cam-lock
screws
Cam locks
3.8 × 45 mm
screws
M6 × 30 mm
bolts
Washers
Screw covers
LABEL HARDWARE QTY.
H2
I8
J10
K6
L7
M1
Anchors
M5 × 15 mm
bolts
M6 × 15 mm
bolts
5 × 50 mm
screws
M6 × 50 mm
bolts
Hex wrench
Drill with M8 bit
(For wall mounting only)HammerPhillips #2 screwdriver Pencil
