5. Product specification
5.1 Type specification(None)
5.2 Electrical parameters
Product Name
UR-BCD595WE-S
Product Code
NS-RTM21SS7
Item
Specification
Specification
Compressor
Compressor
EE50H1C
Starter(PTC)
QPE2-A4R7MD3
Overload protector(OLP)
DRB31T61A1
Winding resistance of compressor
wiring terminal
Rmc:
3.88±7%Ω
Rsc:
4.51±7%Ω
Rms=Rmc+Rsc
Winding resistance picture
Variable frequency driver board
None
Motor
Fan motor of the freezing chamber
DC12V/4W
Ventilation door of the refrigerating
chamber
None
Condensation fan
None
separation the ice motor
None
ice output motor
None
Open door motor
None
None
Lights inside the refrigerator
Lights inside the freezing chamber
None None
Lights inside the refrigerating
chamber
115V/＜3.5W 115V/＜3.5W
Switch of the refrigerator door
Sector
Sector
5.3 Inside temperature
Temperature tolerance ≤ 2
o
C
Compartment
The highest (
o
C)
Lowest (
o
C)
Freezing
-14
-24
Refrigerating
9
1
Variable temperature
/
/
