Service Manual_2017-V1
22
8.3 Light system
Light of the refrigerating chamber is located upper
chamber
1） Remove the lamp cover
2） Remove the bulb
There is a light switch on the side wall of the refrigerating
chamber.
1）Loosen the hook with small normal screwdriver and
pull out the switch until the wire connector reveals.
Pilot light None
Fresh light None
8.4Air duct and fan motor
Air duct components in freezing chamber
All accessories in the freezing chamber should be
dismantled before removing the air duct components.
1） Remove 2 screws on the cover plate of the
freezing air duct using a cross screwdriver.
2） Pull out the connector terminal of the fan motor.
