Insignia NS-RTM21SS7 Service Manual

Service Manual_2017-V1
23
Use screwdriver to remove the 2screws on the back of
Freezer air duct, then remove the front cover, fan
motor assembly can be taken out
Separate the fan blade from fan motor(pull forcibly)
Use screwdriver to remove the screw, then separate
the bracket from fan motor
Change the fan motor, the reverse operation for
assembly
Damper assembly
Damper assembly
None
8.5 Evaporator and temperature sensing system
Evaporator in freezing chamber
