37
Accessory Mounting Dimens
ions
Product Support:
www.instr
on.com
Base beam dimensions
Figure 5. View of base beam fro
m above
Figure 6. Cross-sectional view of base beam
50
25
150
125
62.5
45
4X M6
15
M6
15
45°
45°
55 PCD
12 PCD
3.00
3.13
40.000
40.038
36
38
