System Performance
Product Support: www.instron.com
System Performance
Table 10. 68SC-05 system performance
Parameter Specifications
Testing type Tension, compression, and through zero
operation.
Basic control mode Closed loop position control
Load capacity - kN (lbf) 0.5 (112)
Maximum speed - mm/min (in/min) 2540 (100)
Minimum speed - mm/min (in/min) 0.001 (0.00004)
Maximum force at full speed - kN (lbf) 0.5 (112)
Maximum speed at full force - mm/min (in/min) 2540 (100)
Return speed - mm/min (in/min) 2540 (100)
Crosshead speed accuracy ± 0.1% of set speed at steady state and no
load
Displacement (crosshead position) display accuracy Under no load conditions, equal or less than ±
0.01 mm (0.0004 in) or ±
0.05% of displayed
reading, whichever is greater.
Displacement (crosshead position) repeatability - mm
(in)
± 0.015 (0.0006)
Load measurement accuracy ± 0.5% of reading down to 1/1000 of load cell
capacity.
Strain measurement accuracy ± 0.5% of reading down to 1/50 of full scale
with ASTM E83 class B or ISO 9513 class 0.5
extensometer
Crosshead position control resolution - µm 0.00954
