Chapter: Specifications
36 M10-17411-EN
System weights
The weight value does not include additional accessories such as the Bluehill
®
Operator
Dashboard or any load cell.
Accessory Mounting Dimensions
You can attach numerous testing accessories and fixtures to the load frame for
specialized tests. Use the standard mounting holes shown in the following diagrams to
mount your accessories. Avoid tapping new holes that may weaken or otherwise
compromise the integrity of the load frame.
All measurements in the following figures are shown in mm.
Table 8. System weight
Configuration Weight kg (lb)
Standard load frame 54.5 (120)
Table 9. Meaning of symbols on dimension drawings
Symbol on drawing Meaning
diameter
depth
THRU through-hole
LH left hand thread
RH right hand thread
PCD pitch circle diameter
arrow pointing to the front of the load frame
