33
Product Support: www.instron.com
Chapter 3
Specifications
• 68SC-05 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
• Accessory Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
• System Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
68SC-05 Dimensions and Weight
Frame Dimensions
Load frame dimensions for 68SC-05 frames are shown in Figure 3 on page 34 and
Figure 4 on page 35. Some dimensions are listed in Table 7 on page 33.
Table 7. 68SC-05 dimensions
Letter
Designation Description Dimension - mm (inch)
A Overall height 1015 (40.0)
E2 Maximum vertical test space (test daylight - from
base to underside of crosshead)
738 (29.1)
E1 Minimum vertical test space (test daylight - from
base to underside of crosshead)
233 (9.2)
D Base beam to coupling pin - Type O adapter 22 (.87)
D Base beam to coupling pin - Type D adapter 35 (1.38)
