12
Front & Rear Panels—Continued
m FM ANTENNA
This jack is for connecting an FM antenna.
AM ANTENNA
These push terminals are for connecting an AM
antenna.
n IR IN/OUT
A commercially available IR receiver can be con-
nected to the IR IN jack, allowing you to control the
AV receiver while you’re in Zone 2, or control it
when it’s out of sight, for example, installed in a
cabinet.
A commercially available IR emitter can be con-
nected to the IR OUT jack to pass IR (infrared)
remote control signals through to other components.
o 12V TRIGGER OUT (A/B/C)
These outputs can be connected to the 12-volt trig-
ger inputs on other components.
p AC INLET
The supplied power cord is connected here. The
other end of the power cord should be connected to
a suitable wall outlet.
q GND screw
This screw is for connecting a turntable’s ground
wire.
r PHONO IN
These analog audio inputs are for connecting a turn-
table.
s CD IN
These analog audio inputs are for connecting a CD
player’s analog audio output.
t TV/TAPE IN/OUT
These analog audio inputs and outputs are for con-
necting a TV or recorder with an analog audio input
and output (cassette, Mini Disc, etc.).
u GAME IN
Here you can connect a game console, etc. Input
jacks include S-Video, composite video, and analog
audio.
v CBL/SAT IN
Here you can connect a cable/satellite receiver, set-
top box, etc. Input jacks include S-Video, composite
video, and analog audio.
w VCR/DVR IN/OUT
Here you can connect a VCR or DVR (digital video
recorder). Input and output jacks include S-Video,
composite video, and analog audio.
x DVD/BD IN
Here you can connect a DVD/BD player. Input
jacks include S-Video, composite video, and analog
audio. You can connect a DVD/BD player’s 2-chan-
nel analog audio output.
y PRE OUT: FRONT L/R, CENTER, SURR L/R,
and SURR BACK L/R
These multichannel analog audio outputs can be
connected to the analog audio input on a multichan-
nel power amplifier for when you want to use the
AV receiver solely as a preamplifier.
z PRE OUT: SUBWOOFER
These analog audio outputs can be connected to a
powered subwoofer. You can connect the powered
subwoofer with two PREOUT: SUBWOOFER
jacks respectively. The same signal is output from
each jack.
A PRE OUT: ZONE 2 L/R
These analog audio outputs can be connected to the
line inputs on amplifiers in Zone 2.
B FRONT L/R, CENTER, SURR L/R, SURR
BACK/ZONE 2 L/R, FRONT HIGH L/R, and
FRONT WIDE L/R
These terminal posts are for connecting the front
L/R, center, surround L/R, surround back/ zone 2
L/R, front high L/R, and front wide L/R speakers.
The FRONT L/R and SURR BACK/ZONE 2 L/R
terminal posts can be used with front speakers and
surround back speakers respectively, or used to bi-
amp the front speakers. See “Bi-amping the Front
Speakers” on page 20”.
The SURR BACK/ZONE 2 L/R terminals can be
used with surround back speakers respectively, or
used to connect the speakers in Zone 2.
See “Connecting Zone 2” on page 122.
See pages 17 to 39 for connection information.
To Next Page
