Page #9 background imageLoading...
Page #9 background image
9
Front & Rear Panels—Continued
The page numbers in parentheses show where you can find the main explanation for each item.
o Arrow, Tuning, Preset and Enter buttons
When the AM or FM input source is selected, the
Tuning [q]/[w] buttons are used to tune the tuner,
and the Preset [e]/[r] buttons are used to select
radio presets (see pages 62, 75).
When the onscreen setup menus are used, they work
as arrow buttons and are used to select and set
items. The [Enter] button is also used with the
onscreen setup menus.
p Return button
This button is used to return to the previously dis-
played onscreen setup menu.
q Master Volume control (56)
This control is used to adjust the volume of the AV
receiver to –Q dB, –81.5 dB through +18.0 dB (rel-
ative display).
The volume level can also be displayed as an abso-
lute value. See “Volume Setup” on page 104.
r Zone 2 and Off buttons (125)
The [Zone 2] button is used to turn on the output of
Zone 2.
The [Off] button is used to turn off the output of
Zone 2.
s Zone 2 Level Down and Up [w]/[q] buttons
(126)
Used when adjusting the volume level of Zone 2.
t Phones jack (58)
This 1/4-inch phone jack is for connecting a stan-
dard pair of stereo headphones for private listening.
u AUX Input HDMI (25)
Used to connect a HD camcorder etc.
v Input selector buttons (56)
These buttons are used to select from the following
input sources: DVD/BD, VCR/DVR, CBL/SAT,
Game, AUX, TV/Tape, Tuner, CD, Phono, Port,
Net.
w AUX Input (34)
This input can be used to connect a camcorder,
game console, and so on. There are jacks for com-
posite video, analog audio, and optical digital audio.
x Setup Mic jack (51)
Audyssey MultEQ
®
Room Correction and Speaker
Setup microphone connects here.
