160
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
All channels: North American:
130 watts minimum continuous
power per channel, 8 ohm loads, 2
channels driven from 20 Hz to 20
kHz, with a maximum total
harmonic distortion of 0.08% (FTC)
145 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
160 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
Australian:
7 ch × 180 W at 6 ohms, 1 kHz, 1 ch
driven (IEC)
Maximum Output Power
7 ch × 230 W at 6 ohms, 1 kHz, 1 ch
driven (JEITA)
Dynamic Power 300 W (3 Ω, Front)
250 W (4 Ω, Front)
150 W (8 Ω, Front)
THD (Total Harmonic Distortion)
0.08%
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ, (PHONO MM)
Output Level and Impedance
200 mV/470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB (LINE)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75
Ω
(Component and S-Video Y)
0.7 Vp-p/75
Ω
(Component P
B
/C
B
, P
R
/C
R
)
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz - 3 dB
FM Tuning Frequency Range
North American:
87.5 MHz - 107.9 MHz
Australian:
87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
North American:
530 kHz - 1710 kHz
Australian:
522 kHz - 1611 kHz
Preset Channel 40
Digital Tuner (North American models only):
SIRIUS
Power Supply North American:
AC 120 V, 60 Hz
Australian:
AC 220 - 240 V, 50/60 Hz
Power Consumption North American: 8.1 A
Australian: 750 W
Dimensions (W
× H × D)
435 × 198.5 × 427 mm
17-1/8" × 7-13/16" × 16-13/16"
Weight 17.8 kg (39.2 lbs.)
HDMI IN 1, IN 2, IN 3, IN 4, IN 5, IN6,
AUX(Front)
Component IN 1, IN 2, IN3
S-Video DVD/BD, VCR/DVR, CBL/SAT,
GAME
Composite DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX(Front)
HDMI OUT MAIN, OUT SUB
Component MONITOR OUT, ZONE 2 OUT
S-Video MONITOR OUT, VCR/DVR
Composite MONITOR OUT, VCR/DVR,
ZONE 2 OUT
Digital Inputs Optical: 2 (Rear), 1 (Front)
Coaxial: 3 (Rear)
Analog Inputs DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX(Front), TV/TAPE, CD,
PHONO
Analog Outputs TV/TAPE, VCR/DVR,
ZONE2 PRE OUT, ZONE3 PRE OUT
Multichannel Pre Outputs
7
Subwoofer Pre Outputs
2
Speaker Outputs FL, FR, C, SL/Z3L, SR/Z3R,
SBL/Z2L, SBR/Z2R, LH, RH, LW, RW
Phones 1
MIC Yes
RS232 1
Ethernet 1
IR Input 2
IR Output 1
12 V Trigger Out 3
USB 1
