Appendix
En-119
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (North American)
140 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.05% (FTC)
(Australian)
9 ch × 200 W at 6 ohms, 1 kHz, 1 ch driven
of 1% (IEC)
Maximum Effective Output Power
(Australian)
9 ch × 250 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
320 W (3 Ω, Front)
270 W (4 Ω, Front)
160 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.05% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/470 Ω (PRE OUT)
Maximum RCA Output Level and Impedance
5.5 V/470 Ω (PRE OUT)
Phono Overload 70 mV (MM 1 kHz 0.5% Direct)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (LINE)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Speaker Impedance 4 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
FM Tuning Frequency Range
(North American) 87.5 MHz - 107.9 MHz
(Australian) 87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Digital Tuner (North American) HD Radio
Power Supply (North American) AC 120 V, 60 Hz
(Australian) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American) 11.0 A
(Australian) 1015 W
No-sound Power Consumption
(North American) 150 W
(Australian) 145W
Stand-by Power Consumption
(North American) 0.10 W
(Australian) 0.15 W
Dimensions (W × H × D)
435 mm × 198.5 mm × 455.0 mm
17-1/8" × 7-13/16" × 17-15/16"
Weight 24.5 kg (54.0 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7, IN 8,
AUX INPUT
Output OUT MAIN, OUT SUB/ZONE 2 OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, Lip Sync, CEC (RIHD), HDMI
ZONE 2
Component IN 1, IN 2
Composite IN 1, IN 2, IN 3, IN 4, AUX
Analog RGB PC IN
Component MONITOR OUT
Composite MONITOR OUT, ZONE 2 OUT
Digital Optical: 2 (Rear), 1(Front)
Coaxial: 3
Analog BD/DVD, CBL/SAT, STB/DVR, GAME 1,
PC, TV/CD, PHONO, AUX
Analog PREOUT, ZONE 2 PRE/LINE OUT,
ZONE 3 PRE/LINE OUT,
ZONE 4 PRE/LINE OUT
Analog Multichannel Pre Outputs
11
Subwoofer Pre Outputs
4, ZONE 2 SW, ZONE 3 SW, ZONE 4 SW
Speaker Outputs Main [L, R, C, SL, SR, SBL/Z4L, SBR/Z4R]
+ Front Wide/ZONE 2 (L, R) + Front
High/ZONE 3 (L, R)/Passive SW
Phones 1 (6.3 ø)
Setup Mic 1
RS232 1
RI 1
USB 1 (Front)/1 (Rear)
Ethernet 1
IR Input 2
IR Output 1
12 V Trigger Out 3
