Advanced Operations
En-79
OSD Setup
On Screen Display
` On
` Off
This preference determines whether operation details are
displayed on-screen when an AV receiver function is
adjusted.
Even when “Onis selected, operation details may not be
output if the input source is connected to an HDMI IN.
Language
` English
, Deutsch, Français, Español, Italiano,
Nederlands, Svenska, 中文
This setting determines the language used for the on-screen
menus.
Screen Saver
` 3min
, 5min, 10min
` Off
With this setting, you can set the time until the screen saver
activates itself. Once active, the screen saver will go off
and the screen will return to its previous state if the AV
receiver is operated in any way.
12V Trigger A/B/C Setup
Depending on their type, when some components are
turned by using triggers A, B, and C, a large amount of
current may be drawn at once. To prevent this, you can
delay each trigger signal individually. Another application
of trigger delay is to eliminate the “thump” noise that’s
sometimes heard when a source component is turned on.
You can accomplish this by delaying the trigger signal for
your power amplifier, so that it’s the last component to be
turned on.
Delay
` 0sec, 1sec, 2sec, 3sec:
When “0secis selected, the trigger signal is output
as soon as the input source is changed.
Note
By default, “12V Trigger A Setup” is set to “0sec”, “12V
Trigger B Setup” to “1sec”, and “12V Trigger C Setup” to
2sec”.
Use a miniplug cable to connect the AV receiver’s 12V
TRIGGER OUT A, B, or C jack to the 12 V trigger input of a
connected component.
BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
PC, AUX, TUNER, TV/CD, PHONO, NET, USB
` Off:
No trigger signal is output.
A 12-volt trigger signal is output when the connected
component is selected as the source for:
` Main, Zone 2, Main/Zone 2, Zone 3, Main/Zone 3,
Zone 2/Zone 3, Main/Zone 2/Zone 3, Zone 4,
Main/Zone 4, Zone 2/Zone 4, Main/Zone 2/Zone 4,
Zone 3/Zone 4, Main/Zone 3/Zone 4,
Zone 2/Zone 3/Zone 4, Main/Zone 2/Zone 3/Zone 4
Note
By default, all input sources on the “12V Trigger A Setup” menu
are set to “Main”, those on “12V Trigger B Setup” are set to
Main/Zone 2/Zone 3/Zone 4”, and those on “12V Trigger C
Setup” are set toZone 2”.
Main Menu Hardware Setup
Multi Zone
Zone 2 Out, Zone 3 Out, Zone 4 Out
` Fixed
:
The Zone 2/3/4 volume must be set on the amp in that
zone.
` Variable:
The Zone 2/3/4 volume can be set on the AV
receiver.
If you’ve connected your Zone 2/3/4 speakers to an amp
with no volume control, set the “Zone 2 Out”, “Zone 3
Out”, and “Zone 4 Out” setting, respectively, to
Variable” so that you can set the volume, balance, and
tone of Zone 2/3 and volume of Zone 4 on the AV receiver.
Zone 2 Maximum Volume,
Zone 3 Maximum Volume,
Zone 4 Maximum Volume
` Off
, 50 to 99 (Absolute display)
` Off
, –32dB to +17dB (Relative display)
With this setting, you can limit the maximum volume for
Zone 2/3/4.
Zone 2 Power On Volume,
Zone 3 Power On Volume,
Zone 4 Power On Volume
` Last
, Min, 1 to 99 or Max (Absolute display)
` Last
, QdB, –81dB to +18dB (Relative display)
Hardware Setup
1234 5
Setup
