Advanced Operations
En-64
Speaker Configuration
With these settings, you can specify which speakers are
connected and a crossover frequency for each speaker.
Specify “Full Band” for speakers that can output low
frequency bass sounds adequately, for example, speakers
with a good sized woofer. For smaller speakers, specify a
crossover frequency. Sounds below the crossover
frequency will be output by the subwoofer instead of the
speaker. Refer to your speaker’s manuals to determine the
optimum crossover frequencies. If you set up your
speakers using Audyssey MultEQ XT32 Room Correction
and Speaker Setup, please make sure manually that any
THX speakers are set to “80Hz(THX)” crossover.
■ Subwoofer
` 1ch:
The audio signal is outputted from
SW/SUBWOOFER 1 jack only.
` 2ch
:
The audio signal is outputted from
SW/SUBWOOFER 1 and 2 jacks.
` No
Note
• If the “Passive Subwoofer” setting is set to “Yes”, “No” cannot
be selected here.
■ Front
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
,
90Hz, 100Hz, 110Hz, 120Hz, 130Hz, 150Hz, 200Hz
Note
• If the “Subwoofer” setting is set to “No”, the “Front” setting is
fixed at “Full Band”.
■ Center
*1
, Surround
*1*9
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
,
90Hz, 100Hz, 110Hz, 120Hz, 130Hz, 150Hz, 200Hz
` None
■ Front Wide
*1*3*4*6*7*10
, Front High
*1*2*3*6*10
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX),
90Hz, 100Hz, 110Hz, 120Hz, 130Hz, 150Hz, 200Hz
` None
■ Surround Back
*1*5*6*8*11*12
` Full Band
` 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
,
90Hz, 100Hz, 110Hz, 120Hz, 130Hz, 150Hz, 200Hz
` None
Note
*1
“Full Band” can be selected only when “Full Band” is
selected in the “Front” setting.
*2
When the “Powered Zone 3” setting is set to “Yes”, this
setting cannot be selected.
*3
This setting cannot be selected if the “Speakers Type(Front)”
setting is set to “Bi-Amp” or “Digital Crossover”.
*4
When the “Powered Zone 2” setting is set to “Yes”, this
setting cannot be selected.
*5
When the “Powered Zone 3” setting is set to “Yes”
(➔ page 63) while Powered Zone 2 is enabled (➔ page 86),
this setting cannot be selected.
*6
If the “Surround” setting is set to “None”, this setting cannot
be selected.
*7
If the “11ch Playback” setting is enabled, “None” cannot be
selected.
*8
When the “Speakers Type(Front)” setting is set to “Bi-Amp”
or “Digital Crossover” while Powered Zone 2 is enabled
(➔ page 86), this setting cannot be selected.
*9
When the “Powered Zone 4” setting is set to “Yes” and
Zone 4 is turned on, this setting cannot be selected.
*10
If the “Passive Subwoofer” setting is set to “Yes”
(➔ page 63), this setting cannot be selected.
*11
When the “Powered Zone 4” setting is set to “Yes”, this
setting cannot be selected.
*12
If the “Passive Subwoofer” setting is set to “Yes”
(➔ page 63) while Powered Zone 2 is enabled
(➔ page 86), this setting cannot be selected.
■ Surround Back Ch
` 1ch:
Select if only one surround back speaker L is
connected.
` 2ch
:
Select if two (left and right) surround back speakers
are connected.
Note
• If the “Surround Back” setting is set to “None”, this setting
cannot be selected.
■ LPF of LFE
(Low-Pass Filter for the LFE Channel)
` 80Hz, 90Hz, 100Hz, 110Hz, 120Hz
` Off:
Low-Pass Filter is not applied.
With this setting, you can specify the cutoff frequency of
the LFE channel’s low-pass filter (LPF), which can be
used to filter out unwanted hum. The LPF only applies to
sources that use the LFE channel.
Note
• If you’re using THX-certified speakers, select “80Hz”.
■ Subwoofer Phase
` 0
º
` 180º:
Moves the subwoofer phase.
Note
• If the “Subwoofer” setting is set to “No”, this setting cannot be
selected.
This setting is set automatically by
Audyssey MultEQ
®
XT32 Room Correction and
Speaker Setup function (➔ page 38).
