Chapter 2
Hardware Configuration
Before you install the mainboard into the system chassis,
you may find it convenient to first configure the
mainboard’s hardware. This chapter describes how to set
jumpers and install memory modules, and where to
attach components, however, the CMOS jumper is set on
the “Clear” position when this mainboard is shipped and
you need to set it to the “Normal” position in order for
the mainboard perform properly.
Warning: Set RTC to “Normal” position before setting other
jumpers or memory modules. This mainboard will
not function properly if you fail to do so.
