J19/J20 – Analog Audio from CD-ROM
Connect from “AUDIO” output of the CD-ROM driver to
these connectors. For Panasonic or compatible type of
CD-ROM, connect to J20 (pin signals assignment is G-L-
G-R), and for Sony or compatible type of CD-ROM,
connect to J19 (pin signals assignment is L-G-G-R).
+
Chipset
Sound Pro
VGA
Chipset
I/O Chip
1
J19
J20
1
J19
J20
