38 Chapter 3
OffBoard PCI
IDE Card
This option specifies if an offboard PCI IDE
controller adapter card is installed in the
computer. You must specify the PCI expansion
slot on the motherboard where the offboard
PCI IDE controller is installed. If an offboard
PCI IDE controller is used, the onboard IDE
controller is automatically disabled. If an
offboard PCI IDE controller adapter card is
installed in the computer, you must also set the
Offboard PCI IDE Primary IRQ and
Offboard PCI IDE Secondary IRQ options.
IDE Primary
IRQ;
IDE Secondary
IRQ
These options specify the PCI interrupt used by
the Primary (or secondary) IDE channel on the
offboard PCI IDE controller.
DMA Channel 0,
1, 3, 5, 6, 7
These options specify the bus that the specified
DMA channel is used on.
IRQ3, 4, 5, 7, 9,
10, 11, 14, 15
These options specify the bus that the specified
IRQ line is used on. These options allow you to
reserve IRQs for legacy ISA adapter cards.
Reserved
Memory Size
This option is designed to be used for reserving
memory for the IO card.
Reserved
Memory Address
This option is designed to be used for reserving
memory address for the IO card.
