Intel 8XC251SA

8XC251SA, SB, SP, SQ USER’S MANUAL
A-124
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(Rmd) ← (Rmd) – (Rms)
SUB WRjd,WRjs
Binary Mode Source Mode
Bytes: 32
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(WRjd) ← (WRjd) – (WRjs)
SUB DRkd,DRks
Binary Mode Source Mode
Bytes: 32
States: 54
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(DRkd) ← (DRkd) – (DRks)
SUB Rm,#data
Binary Mode Source Mode
Bytes: 43
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(Rm) ← (Rm) – #data
SUB WRj,#data16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding] 1 0 0 1 1 1 0 1 t t t t T T T T
[Encoding] 1 0 0 1 1 1 1 1 u u u u U U U U
[Encoding] 1 0 0 1 1 1 1 0 s s s s 0 0 0 0 #data
