Intel 8XC251SA

8XC251SA, SB, SP, SQ USER’S MANUAL
A-126
SUB Rm,dir16
Binary Mode Source Mode
Bytes: 54
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(Rm) ← (Rm) – (dir16)
SUB WRj,dir16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(WRj) ← (WRj) – (dir16)
SUB Rm,@WRj
Binary Mode Source Mode
Bytes: 43
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: SUB
(Rm) ← (Rm) – ((WRj))
SUB Rm,@DRk
Binary Mode Source Mode
Bytes: 43
States: 43
1 0 0 1 1 1 1 0 s s s s 0 0 1 1 direct addr direct addr
1 0 0 1 1 1 1 0 t t t t 0 1 1 1 direct addr direct addr
1 0 0 1 1 1 1 0 t t t t 1 0 0 1 s s s s 0 0 0 0
