8XC251SA, SB, SP, SQ USER’S MANUAL
A-136
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: XRL
(WRj) ← (WRj) ∀ (dir8)
XRL Rm,dir16
Binary Mode Source Mode
Bytes: 54
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: XRL
(Rm) ← (Rm) ∀ (dir16)
\XRL WRj,dir16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: XRL
(WRj) ← (WRj) ∀ (dir16)
XRL Rm,@Wrj
Binary Mode Source Mode
Bytes: 43
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: XRL
(Rm) ← (Rm) ∀ ((WRj))
0 1 1 0 1 1 1 0 s s s s 0 0 1 1 direct addr dir8 addr
0 1 1 0 1 1 1 0 t t t t 0 1 1 1 direct addr direct addr
0 1 1 0 1 1 1 0 t t t t 1 0 0 1 s s s s 0 0 0 0
