Intel Desktop Board D945GCCR Technical Product Specification
10
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
Form Factor microATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Duo processor in an LGA775 socket with a 800 MHz system bus
• Intel
®
Pentium
®
D processor in an LGA775 socket with an 800 or 533 MHz
system bus
• Intel
®
Pentium
®
4 processor in an LGA775 socket with an 800 or 533 MHz
system bus
• Intel
®
Celeron
®
D processor in an LGA775 socket with a 533 MHz system bus
Memory
• Two 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 533 or DDR2 400 MHz DIMMs
• Support for up to 4 GB of system memory
Chipset
Intel
®
945GC Chipset, consisting of:
• Intel
®
82945GC Graphics Memory Controller Hub (GMCH)
• Intel
®
82801GB I/O Controller Hub (ICH7)
Video Intel
®
GMA950 onboard graphics subsystem
Audio 6-channel (5.1) audio subsystem with three analog audio outputs using the
Realtek* ALC883 audio codec
Legacy I/O Control SMSC* 5127 legacy I/O controller for diskette drive, serial, parallel, and PS/2*
ports
USB Support for USB 2.0 devices
Peripheral
Interfaces
• Eight USB ports
• One serial port
• One parallel port
• Four Serial ATA interfaces
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2 keyboard and mouse ports
LAN Support 10/100 Mbits/sec LAN subsystem using the Intel
®
82562G Platform LAN Connect
(PLC) device
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Expansion
Capabilities
• Two PCI* Conventional bus connectors
• One PCI Express* x1 bus add-in card connector
• One PCI Express x16 bus add-in card connector
continued
