Intel Desktop Board D945GCCR Technical Product Specification
52
Table 16. Front Panel Audio Header
Pin Signal Name Pin Signal Name
1 Port E [Port 1] Left Channel 2 Ground
3 Port E [Port 1] Right Channel 4 Presence# (dongle present)
5 Port F [Port 2] Right Channel 6 Port E [Port 1] Sense return
(jack detection)
7 Port E [Port 1] and Port F [Port 2]
Sense send (jack detection)
8 Key
9 Port F [Port 2] Left Channel 10 Port F [Port 2] Sense return
(jack detection)
#
INTEGRATOR’S NOTE
The front panel audio header is colored yellow.
Table 17. Chassis Intrusion Header
Pin Signal Name
1 Intruder
2 Ground
Table 18. Serial ATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 19. Processor Fan Header
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Table 20. Front and Rear Chassis Fan Headers
Pin Signal Name
1 FAN_CONTROL
2 +12 V
3 FAN_TACH
