1.10.4 Thermal Monitoring
Figure 9 shows the location of the sensors and fan headers.
Item Description
A
Processor fan
B
Rear chassis fan
C
Thermal diode, located on processor die
D
Remote ambient temperature sensor
E
Front chassis fan
Figure 9. Thermal Sensors and Fan Headers
