Intel Desktop Board D945GCCR Technical Product Specification
48
2.7 Connectors and Headers
CAUTION
Only the following connectors have overcurrent protection: back panel USB, front
panel USB, and PS/2.
The other internal connectors/headers are not overcurrent protected and should
connect only to devices inside the computer’s chassis, such as fans and internal
peripherals. Do not use these connectors/headers to power devices external to the
computer’s chassis. A fault in the load presented by the external devices could cause
damage to the computer, the power cable, and the external devices themselves.
This section describes the board’s connectors and headers. The connectors and
headers can be divided into these groups:
• Back panel connectors (see page
49)
• Component-side connectors and headers (see page
50)
