Technical Reference
65
Figure 19 shows the locations of the localized high temperature zones.
Item Description
A Processor voltage regulator area
B Processor
C Intel
82945GC GMCH
D Intel
82801GB ICH7
Figure 19. Localized High Temperature Zones
