Intel BLKD945GCCR - Component-Side Connectors and Headers Shown in Figure 13

Technical Reference
51
Table 15 lists the component-side connectors and headers identified in Figure 13.
Table 15. Component-side Connectors and Headers Shown in
Figure 13
Item/callout
from
Figure 13 Description
A
Front panel audio header
B
PCI Conventional bus add-in card connector 2
C
PCI Conventional bus add-in card connector 1
D
PCI Express x1 bus add-in card connector
E
PCI Express x16 bus add-in card connector
F
Processor core power connector
G
Processor fan header
H
Rear chassis fan header
I
Chassis intrusion header
J
Main power connector
K
Diskette drive connector
L
Parallel ATA IDE connector
M
Front chassis fan header
N
Serial ATA connector 1
O
Serial ATA connector 3
P
Serial ATA connector 2
Q
Front panel header
R
Serial ATA connector 0
S
Front panel USB header
T
Front panel USB header
U
Auxiliary front panel power LED header
