Intel BLKD945GCCR - Board Components Shown in Figure 1

Product Description
13
Table 2. Board Components Shown in Figure 1
Item/callout
from
Figure 1 Description
A
Front panel audio header
B
PCI Conventional bus add-in card connector #2
C
PCI Conventional bus add-in card connector #1
D
PCI Express x1 bus add-in card connector
E
PCI Express x16 bus add-in card connector
F
Back panel connectors
G
Processor core power connector
H
Processor fan header
I
Rear chassis fan header
J
LGA775 processor socket
K
Intel 82945GC GMCH
L
DIMM socket
M
DIMM socket
N
Chassis intrusion header
O
Main Power connector
P
Diskette drive connector
Q
Parallel ATE IDE connector
R
Intel 82801GB I/O Controller Hub (ICH7)
S
Front chassis fan header
T
Serial ATA connectors [4]
U
Front panel header
V
Speaker
W
Front panel USB headers [2]
X
BIOS Setup configuration jumper block
Y
Battery
Z
Auxiliary front panel power LED header
