Intel Desktop Board D945GCCR Technical Product Specification
28
1.8.3 6-Channel (5.1) Audio Subsystem
The 6-channel (5.1) audio subsystem includes the following:
• Intel 82801GB I/O Controller Hub (ICH7)
• Realtek ALC883 audio codec
• Microphone input that supports a single dynamic, condenser, or electret
microphone
The back panel audio connectors are configurable through the audio device drivers.
The available configurable audio ports are shown in
Figure 7.
Figure 7. Front/Back Panel Audio Connector Options
For information about Refer to
The back panel audio connectors Section
2.7.1, page 49
