Intel Desktop Board CA810E Product Guide
42
Advanced Menu
This menu is for setting advanced features that are available through the chipset.
Table 9. Advanced Menu
Feature Options Description
Extended Configuration No options Indicates whether extended configuration settings have
been modified from the default setting.
PCI Configuration No options Allows access to PCI IRQ mapping.
Boot Configuration No options Configures Plug and Play and the Numlock key, and resets
configuration data. When selected, displays the Boot
Settings Configuration submenu.
Peripheral Configuration No options Configures peripheral ports and devices. When selected,
displays the Peripheral Configuration submenu.
IDE Configuration No options Specifies type of connected IDE device.
Diskette Configuration No options When selected, displays the Floppy Options submenu.
Event Log Configuration No options Configures Event Logging. When selected, displays the
Event Log Configuration submenu.
Video Configuration No options Configures video features. When selected, displays the
Video Configuration submenu.
PCI Configuration Submenu
This menu is for accessing PCI IRQ mapping.
Table 10. PCI Configuration Submenu
Feature Options Description
PCI Slot 1 IRQ Priority • Auto (default)
• 9
• 10
• 11
Allows the user to map the PCI IRQ for slot 1 to a
particular hardware interrupt.
PCI Slot 2 IRQ Priority • Auto (default)
• 9
• 10
• 11
Allows the user to map the PCI IRQ for slot 2 to a
particular hardware interrupt.
PCI Slot 3 IRQ Priority • Auto (default)
• 9
• 10
• 11
Allows the user to map the PCI IRQ for slot 3 to a
particular hardware interrupt.
PCI Slot 4 IRQ Priority • Auto (default)
• 9
• 10
• 11
Allows the user to map the PCI IRQ for slot 4 to a
particular hardware interrupt.
