IDE Configuration Submenus
This submenu is for configuring IDE devices, including:
• Primary IDE master
• Primary IDE slave
• Secondary IDE master
• Secondary IDE slave
Table 14. IDE Configuration Submenus
Feature Options Description
Type • None
• User
• Auto (default)
• CD-ROM
• ATAPI Removable
• Other ATAPI
• IDE Removable
Specifies the IDE configuration mode for IDE devices.
User allows the user to change the LBA Mode Control,
Multi-Sector Transfers, PIO Mode, and Ultra DMA
settings.
Auto automatically sets the LBA Mode Control, Multi-
Sector Transfers, PIO Mode, and Ultra DMA settings.
LBA Mode Control • Disabled
• Enabled (default)
Enables or disables the LBA mode control.
Multi-Sector Transfers • Disabled
• 2 Sectors
• 4 Sectors
• 8 Sectors
• 16 Sectors (default)
Specifies number of sectors per block for transfers
from the hard disk drive to memory.
Check the hard disk drive’s specifications for optimum
setting.
PIO Mode • Auto (default)
• 0
• 1
• 2
• 3
• 4
Specifies the method for moving data to/from the drive.
Ultra DMA • Disabled (default)
• Mode 0
• Mode 1
• Mode 2
• Mode 3
• Mode 4
Specifies the Ultra DMA mode for the drive.
