Table 12. Peripheral Configuration Submenu (continued)
Feature Options Description
Base I/O address • 2F8 (default)
• 3E8
• 2E8
Specifies the base I/O address for serial port B.
Interrupt • IRQ 3 (default)
• IRQ 4
Specifies the interrupt for serial port B.
Parallel port • Disabled
• Enabled
• Auto (default)
Configures the parallel port.
Auto assigns LPT1 the address 378h and the interrupt IRQ7.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Mode • Output Only
• Bi-directional
(default)
• EPP
• ECP
Selects the mode for the parallel port. Not available if the
parallel port is disabled.
Output Only operates in AT
†
-compatible mode.
Bi-directional operates in PS/2-compatible mode.
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed bi-
directional mode.
Base I/O address • 378 (default)
• 278
• 228
Specifies the base I/O address for the parallel port.
Interrupt • IRQ 5
• IRQ 7 (default)
Specifies the interrupt for the parallel port.
Audio Device • Disabled
• Enabled
(default)
Enables or disables the onboard audio subsystem.
LAN Device • Disabled
• Enabled
(default)
Enables or disables the optional onboard 10/100 Ethernet.
Legacy USB Support • Disabled
• Enabled
• Auto (default)
Enables or disables USB legacy support.
