Error Messages and Beep Codes
125
Table 92. Runtime Code Uncompressed in F000 Shadow RAM (continued)
Code Description of POST Operation
AE Uncompress SMBIOS module and init SMBIOS code and form the runtime SMBIOS image in
shadow.
B1 Going to copy any code to specific area.
00 Copying of code to specific area done. Going to give control to INT-19 boot loader.
5.3 Bus Initialization Checkpoints
The system BIOS gives control to the different buses at several checkpoints to do various tasks.
Table 93 describes the bus initialization checkpoints.
Table 93. Bus Initialization Checkpoints
Checkpoint Description
2A Different buses init (system, static, and output devices) to start if present.
38 Different buses init (input, IPL, and general devices) to start if present.
39 Display different buses initialization error messages.
95 Init of different buses optional ROMs from C800 to start.
While control is inside the different bus routines, additional checkpoints are output to port 80h as
WORD to identify the routines under execution. In these WORD checkpoints, the low byte of the
checkpoint is the system BIOS checkpoint from which the control is passed to the different bus
routines. The high byte of the checkpoint is the indication of which routine is being executed in
the different buses. Table 94 describes the upper nibble of the high byte and indicates the function
that is being executed.
Table 94. Upper Nibble High Byte Functions
Value Description
0 func#0, disable all devices on the bus concerned.
1 func#1, static devices init on the bus concerned.
2 func#2, output device init on the bus concerned.
3 func#3, input device init on the bus concerned.
4 func#4, IPL device init on the bus concerned.
5 func#5, general device init on the bus concerned.
6 func#6, error reporting for the bus concerned.
7 func#7, add-on ROM init for all buses.
