Intel D845PEBT2 User Manual

Technical Reference
69
Table 45. Front Panel Audio Connector
Pin Signal Name Pin Signal Name
1 MIC_IN_FP 2 Ground
3 MIC_BIAS 4 V_5P0_AUD_ANALOG
5 R_FNTOUT 6 R_RETIN
7 Not connected 8 Key
9 L_FNT_OUT 10 L_RETIN
✏
NOTE
The front panel audio connector is alternately used as a jumper block for routing audio signals.
For more information, see Section 2.9.1 on page 72.
Table 46. Front Panel USB Connector
Pin Signal Name Pin Signal Name
1 USB_FNT_PWR 2 USB_FNT_PWR
3 USB_FNT1# 4 USB_FNT2#
5 USB_FNT1 6 USB_FNT2
7 Ground 8 Ground
9 Not connected 10 Not connected
Table 47. Front Panel IEEE 1394a-2000 Connectors (Optional)
Pin Signal Name
1 TPA1+ [TPA2+]
2 TPA1- [TPA2-]
3 Ground
4 Ground
5 TPB1+ [TPB2+]
6 TPB1- [TPB2-]
7 +12 V (Fused)
8 +12 V (Fused)
9 Key
10 Ground
Signal names in brackets [ ] are for the second IEEE 1394a-2000 connector.
