Intel Desktop Board D845PEBT2 Technical Product Specification
36
1.15.1.2 Thermal Monitoring
Figure 9 shows the location of the sensors and fan connectors.
OM15032
F
A
B
D
C
E
A Thermal diode, located on processor die
B Remote ambient temperature sensor
C Ambient temperature sensor, internal to
hardware monitoring ASIC
D Processor fan
E Rear chassis fan
F Front chassis fan
Figure 9. Thermal Monitoring
1.15.2 Fan Monitoring
Fan monitoring can be implemented using Intel
®
Active Monitor, Intel
®
LANDesk
®
Client
Manager, or third-party software.
For information about Refer to
The functions of the fan connectors Section 1.16.2.2, page 41
