Intel Desktop Board D845PEBT2 Technical Product Specification
24
1.7.1 AGP
AGP is a high-performance interface for graphics-intensive applications, such as 3D applications.
While based on the PCI Local Bus Specification, Rev. 2.2, AGP is independent of the PCI bus and
is intended for exclusive use with graphical display devices. AGP overcomes certain limitations of
the PCI bus related to handling large amounts of graphics data with the following features:
• Pipelined memory read and write operations that hide memory access latency
• Demultiplexing of address and data on the bus for nearly 100 percent efficiency
✏
NOTES
• The AGP connector is keyed for 1.5 V Switching Voltage Level (SVL) AGP cards only; the
connector is not mechanically compatible with legacy 3.3 V AGP cards. Do not attempt to
install a legacy 3.3 V AGP card.
• Install memory in the DIMM sockets prior to installing the AGP video card to avoid
interference with the memory retention mechanism.
For information about Refer to
The location of the AGP connector Figure 1, page 14
The signal names of the AGP connector Table 38, page 64
Obtaining the Accelerated Graphics Port Interface Specification Section 1.4, page 17
1.7.2 USB
The Desktop Board D845PEBT2 supports up to six USB 2.0 ports, fully supports UHCI and EHCI,
and uses UHCI- and EHCI-compatible drivers.
The ICH4 provides the USB controller for all ports, as shown in Figure 4. The port arrangement is
as follows:
• Two ports are implemented with stacked back panel connectors, adjacent to the PS/2
connectors
• Two ports are implemented with stacked back panel connectors, adjacent to the audio
connectors
• Two ports are routed to the front panel USB connector
OM14260
82801DB
I/O Controller Hub
(ICH4)
USB
USB
USB
USB ports (2)
USB ports (2)
Back panel USB connectors
adjacent to the PS/2 ports
USB ports (2)
Back panel USB connectors
adjacent to the audio connectors
Front panel USB connectors
Figure 4. USB Port Configuration
