Intel Desktop Board D845PEBT2 Technical Product Specification
46
2.3 Fixed I/O Map
Table 11. I/O Map
Address (hex) Size Description
0000 - 00FF 256 bytes Used by the Desktop Board D845PEBT2. Refer to the
ICH4 data sheet for dynamic addressing information
0170 - 0177 8 bytes Secondary IDE channel
01F0 - 01F7 8 bytes Primary IDE channel
0228 - 022F
(Note 1)
8 bytes LPT3
0278 - 027F
(Note 1)
8 bytes LPT2
02E8 - 02EF
(Note 1)
8 bytes COM4/video (8514A)
02F8 - 02FF
(Note 1)
8 bytes COM2
0376 1 byte Secondary IDE channel command port
0377, bits 6:0 7 bits Secondary IDE channel status port
0378 - 037F 8 bytes LPT1
03B0 - 03BB 12 bytes Intel 82845PE MCH
03C0 - 03DF 32 bytes Intel 82845PE MCH
03E8 - 03EF 8 bytes COM3
03F0 - 03F5 6 bytes Diskette channel 1
03F6 1 byte Primary IDE channel command port
03F8 - 03FF 8 bytes COM1
04D0 - 04D1 2 bytes Edge/level triggered PIC
LPTn + 400 8 bytes ECP port, LPTn base address + 400h
0CF8 - 0CFB
(Note 2)
4 bytes PCI configuration address register
0CF9
(Note 3)
1 byte Turbo and reset control register
0CFC - 0CFF 4 bytes PCI configuration data register
FFA0 - FFA7 8 bytes Primary bus master IDE registers
FFA8 - FFAF 8 bytes Secondary bus master IDE registers
Notes:
1. Default, but can be changed to another address range
2. Dword access only
3. Byte access only
For information about Refer to
ICH4 addressing Section 1.2, page 16
