Intel Desktop Board D845PEBT2 Technical Product Specification
60
Table 33. Main Power Connector
Pin Signal Name Pin Signal Name
1 +3.3 V 11 +3.3 V
2 +3.3 V 12 -12 V
3 Ground 13 Ground
4 +5 V 14 PS-ON# (power supply remote on/off)
5 Ground 15 Ground
6 +5 V 16 Ground
7 Ground 17 Ground
8 PWRGD (Power Good) 18 Not connected
9 +5 V (Standby) 19 +5 V
10 +12 V 20 +5 V
Table 34. Chassis Intrusion Connector
Pin Signal Name
1 Intruder
2 Ground
Table 35. Front Chassis Fan Connector
Pin Signal Name
1 Control
2 +12 V
3 FRONT_FAN_TACH
