Product Description
29
1.10.4 Keyboard and Mouse Interface
The PS/2 keyboard and mouse connectors are located on the back panel.
✏
NOTE
The keyboard is supported in the bottom PS/2 connector and the mouse is supported in the top
PS/2 connector. Power to the computer should be turned off before a keyboard or mouse is
connected or disconnected.
For information about Refer to
The location of the keyboard and mouse connectors Figure 11, page 52
The signal names of the keyboard and mouse connectors Table 16, page 53
1.11 IEEE 1394a-2000 Controller (Optional)
The Agere Systems FW323 PCI bus-based controller provides IEEE 1394a-2000 OHCI link and
PHY core functionality. The controller supports:
• IEEE 1394a-2000-compliant or IEEE 1394-1995-compliant peripheral devices
• Isochronous and asynchronous data transfer
• Data transfer up to 400 Mbits/sec
• Peripheral hot swapping
• Plug and play
The Desktop Board D845PEBT2 has one back panel and two front panel IEEE 1394a-2000
connectors.
✏
NOTE
IEEE 1394a-2000 support has been tested with Windows 2000 and Windows XP drivers and is not
currently supported by any other operating system.
For information about Refer to
The location of the back panel IEEE 1394a-2000 connector Figure 11, page 52
The signal names of the back panel IEEE 1394a-2000 connector Table 17, page 53
The location of the front panel IEEE 1394a-2000 connectors Figure 15, page 68
The signal names of the front panel IEEE 1394a-2000 connectors Table 47, page 69
Obtaining IEEE standards:
• 1394-1995, IEEE Standard for a High Performance Serial Bus
• 1394a-2000, IEEE Standard for a High Performance Serial Bus – Amendment 1
Table 3, page 17
