Intel Desktop Board D845PEBT2 Technical Product Specification
20
1.5 Processor
✏
NOTE
Refer to Thermal Considerations (Section 2.12, page 83) for important information when using an
Intel Pentium 4 processor operating above 2.80 GHz with this Intel desktop board.
CAUTION
Use of unsupported processors can damage the Desktop Board D845PEBT2, the processor, and
the power supply. See Intel’s World Wide Web site for the most up-to-date list of supported
processors for the Desktop Board D845PEBT2.
The Desktop Board D845PEBT2 supports:
• An Intel Pentium 4 processor in an mPGA478 socket with a system bus of 400/533 MHz
• An Intel Celeron processor in an mPGA478 socket with a system bus of 400 MHz
The list of supported processors for the Desktop Board D845PEBT2 is available from Intel’s
World Wide Web site. All supported onboard memory can be cached. See the processor’s data
sheet for cachability limits.
✏
NOTE
Do not use a standard ATX power supply. The Desktop Board D845PEBT2 will not boot with a
standard ATX power supply. Use only ATX12V-compliant power supplies with the Desktop Board
D845PEBT2. ATX12V power supplies have an additional power lead that provides required
supplemental power for the processor. Connect the 20-pin and 4-pin leads of ATX12V power
supplies to the corresponding connectors on the Desktop Board D845PEBT2 or it will not boot.
For information about Refer to
Supported processors Section 1.2, page 16
Processor data sheets Section 1.2, page 16
Power supply connectors Section 2.8.2.2, page 58
