Intel Desktop Board DG41TY Product Guide
12
Table 2. Intel Desktop Board DG41TY Components
Label Description
A PCI bus connector 2
B PCI bus connector 1
C PCI Express x1 connector
D PCI Express x16 connector
E Rear chassis fan header (3-pin)
F Back panel connectors
G 12 V processor core voltage connector (2 x 2 pin)
H Processor socket
I Processor fan header (4-pin)
J DDR2 Channel A DIMM 0 socket
K DDR2 Channel B DIMM 0 socket
L Main power connector (2 x 12 pin)
M IDE connector
N Battery
O Front chassis fan header (3-pin)
P Serial ATA connectors (4)
Q Chassis intrusion header
R Front panel header
S HD Audio Link header
T Alternate front panel power LED header
U BIOS configuration jumper block
V High-speed USB 2.0 headers (2)
WW Speaker
X Diskette drive connector
Y Serial port header
Z S/PDIF connector
AA Front panel audio header
BB Front panel audio select jumper block

Intel DG41TY Specifications

General

Form Factor	MicroATX
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2
Maximum Memory	8 GB
Graphics	Intel Graphics Media Accelerator X4500
LAN	10/100/1000 Mbps
Expansion Slots	1 x PCIe x16, 2 x PCIe x1, 1 x PCI
Storage Interface	4 x SATA 3.0 Gb/s
USB Ports	8 x USB 2.0
Video Outputs	VGA
RAID Support	No
IDE Ports	1 x IDE
Chipset	Intel G41 Express
