Intel Desktop Board DG41TY Product Guide
24
Related Links:
For more information on standby current requirements for the Desktop Board, refer to
the Technical Product Specification by going to the following link, finding the product,
and selecting Product Documentation from the left-hand menu:
http://support.intel.com/support/motherboards/desktop/
Wake from USB
NOTE
Wake from USB requires the use of a USB peripheral that supports Wake from USB.
USB bus activity wakes the computer from an ACPI S1 or S3 state.
PME# Signal Wake-up Support
When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI
S1, S3, S4, or S5 (LAN only) state.
WAKE# Signal Wake-up Support
When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from
an ACPI S1, S3, S4, or S5 (LAN only) state.
ENERGY STAR* Capable
In 2007, the US Department of Energy and the US Environmental Protection Agency
revised the ENERGY STAR requirements. Intel worked directly with these two
governmental agencies to define the new requirements. This Desktop Board meets
the ENERGY STAR Category B requirements.
For more information concerning ENERGY STAR, go to
http://www.intel.com/go/EnergyStar
Speaker
A speaker is mounted on the Desktop Board. The speaker provides audible error code
(beep code) information during the Power-On Self-Test (POST).
Battery
A battery on the Desktop Board keeps the values in CMOS RAM and the clock current
when the computer is turned off. Go to page 55 for instructions on how to replace the
battery.
