Intel Desktop Board DG41TY Product Guide
72
Table 19 shows the lead-free board markings as they appear on the board and
accompanying collateral.
Table 19. Lead-Free Board Markings
Description Mark
Lead-Free 2
nd
Level
Interconnect: This symbol
is used to identify electrical
and electronic assemblies and
components in which the lead
(Pb) concentration level in the
Intel Desktop Board substrate
and the solder connections
from the board to the
components (second-level
interconnect) is not greater
than 0.1% by weight (1000
ppm).
or
or
China
RoHS/Environmentally
Friendly Use Period Logo:
This is an example of the
symbol used on Intel Desktop
Boards and associated
collateral. The color of the
mark may vary depending
upon the application. The
Environmental Friendly Usage
Period (EFUP) for Intel
Desktop Boards has been
determined to be 10 years.
