Intel Desktop Board DQ965CO Technical Product Specification
12
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Desktop Board DQ965CO.
Table 1. Feature Summary
Form Factor microBTX Form Factor (10.40 inches by 10.50 inches [264.16 millimeters by
266.70 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Duo processor in an LGA775 socket with a 1066 or 800 MHz
system bus
• Intel
®
Pentium
®
D processor in an LGA775 socket with an 800 or 533 MHz
system bus
• Intel
®
Pentium
®
4 processor in an LGA775 socket with an 800 or 533 MHz
system bus
• Intel
®
Celeron
®
D processor in an LGA775 socket with a 533 MHz system bus
Memory
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 800, DDR2 667, or DDR2 533 MHz DIMMs
• Support for up to 8 GB of system memory using DDR2 667 or DDR2 533
DIMMs
• Support for up to 4 GB of system memory using DDR2 800 DIMMs
Chipset
Intel
®
Q965 Express Chipset, consisting of:
• Intel
®
82Q965 Graphics Memory Controller Hub (GMCH)
• Intel
®
82801HO I/O Controller Hub (ICH8DO)
Video Intel
®
GMA 3000 onboard graphics subsystem
Audio 6-channel (5.1) audio subsystem using the SigmaTel* STAC9227 audio codec
Legacy I/O Control Legacy I/O controller for diskette drive, serial, parallel, and optional PS/2* ports
USB Support for USB 2.0 devices
Peripheral
Interfaces
• 10 USB ports
• Two IEEE-1394a interfaces: one back panel connector and one front-panel
header
• One serial port
• One parallel port
• Six Serial ATA interfaces
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100/133 support
• One diskette drive interface
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel
®
82566DM
Gigabit Ethernet Controller
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Trusted Platform
Module (TPM),
revision 1.2
A component that enhances platform security
continued
