Intel Desktop Board DQ965CO Technical Product Specification
36
1.10 LAN Subsystem
The LAN subsystem consists of the following:
• Intel 82566DM Gigabit (10/100/1000 Mbits/sec) Ethernet LAN controller
• Intel 82801HO ICH8DO
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between ICH8DO and LAN controller
• PCI Conventional bus power management
⎯ Supports ACPI technology
⎯ Supports LAN wake capabilities
⎯ LAN Subsystem Software
LAN software and drivers are available from Intel’s World Wide Web site.
1.10.1 Intel
®
82566DM Gigabit Ethernet Controller
The Intel 82566DM Gigabit Ethernet Controller supports the following features:
• PCI Express link
• 10/100/1000 IEEE 802.3 compliant
• Compliant to IEEE 802.3x flow control support
• Jumbo frame support
• TCP, IP, UDP checksum offload
• Transmit TCP segmentation
• Advanced packet filtering
• Full device driver compatibility
• PCI Express Power Management Support
The Intel 82566DM also provides support for:
• Alert Standard Format (ASF) 2.0
• Intel
®
Active Management Technology (Intel
®
AMT)
• Virtual LAN driver support for Intel VT partitions
1.10.2 LAN Subsystem Software
LAN software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining LAN software and drivers Section
1.2, page 17
