Intel DQ965CO User Manual

Product Description
15
Table 3. Board Components Shown in Figure 1
Item/callout
from
Figure 1 Description
A Back panel connectors
B High Definition Audio header
C Remote thermal sensor
D Serial ATA connectors [6]
E Front panel USB headers [2]
F Intel 82801HO I/O Controller Hub (ICH8DO)
G Chassis intrusion header
H PCI Express x16 connector
I PCI Express x1 connector
J PCI Conventional bus add-in card connectors [2]
K IEEE-1394a front panel header
L Diskette drive connector
M Parallel ATE IDE connector
N Serial port header
O Front panel header
P Front chassis fan header
Q Auxiliary front panel power LED header
R Parallel port header
S Speaker
T LGA775 processor socket
U Intel 82Q965 GMCH
V Processor core power connector
W Processor fan header
X DIMM Channel A sockets
Y DIMM Channel B sockets
Z Rear chassis fan header
AA Battery
BB Main Power connector
CC BIOS Setup configuration jumper block
DD Front panel audio header

Intel DQ965CO Specifications

General

Brand	Intel
Model	DQ965CO
Category	Motherboard
Language	English
