Intel DQ965CO User Manual

Technical Reference
59
Table 18 lists the component-side connectors and headers identified in Figure 16.
Table 18. Component-side Connectors and Headers Shown in
Figure 16
Item/callout
from
Figure 16 Description
A High Definition Audio Link header
B Serial ATA connectors [6]
C Front panel USB headers [2]
D Chassis intrusion header
E PCI Express x16 add-in card connector
F PCI Express x1 add-in card connector
G PCI Conventional bus add-in card connector 1
H PCI Conventional bus add-in card connector 2
I IEEE-1394a front panel header
J Diskette drive connector
K Parallel ATA IDE connector
L Serial port header
M Front panel header
N Front chassis fan header
O Auxiliary front panel power LED header
P Parallel port header
Q Processor core power connector
R Processor fan connector
S Rear chassis fan header
T Main power connector
U Front panel audio header
