Intel DQ965CO

Intel Desktop Board DQ965CO Technical Product Specification
68
2.9 Mechanical Considerations
2.9.1 Form Factor
The board is designed to fit into a BTX-form-factor chassis. Figure 21 illustrates the
mechanical form factor of the board. Dimensions are given in inches [millimeters].
The outer dimensions are 10.40 inches by 10.50 inches [264.16 millimeters by 266.70
millimeters].
OM18319
10.000
[254.00]
9.550
[242.57]
2.275
[57.79]
10.000
[254.00]
10.250
[260.36]
0.200
[5.08]
10.200
[259.08]
0.250
[6.35]
9.150
[232.41]
7.550
[191.77]
0.00
0.00
Figure 21. Board Dimensions
