Ethernet Network Adapter E810-CQDA2T
User Guide
12 722960-002
2.5 Connectivity and Interoperability
E810-CQDA2T samples have been validated or verified with the following accessories. Contact your
Intel representative if you require sample units (where available).
2.5.1 E810-CQDA2T Support for PSM4 Modules Including Breakout
Cables
To install the Intel 100G PSM4 Optical Transceiver:
1. Locate the QSFP28 cage slot on the host or switch equipment.
2. With the optical module oriented with the pull-tab on top, firmly push the optical transceiver into
the QSFP28 cage slot on the host or switch equipment.
3. For QSFP28 modules with an optical receptacle-type connector, plug the optical connector of the
fiber optic cable into the optical connector receptacle of the QSFP28 module. For pigtailed products,
plug the fiber connector on the end of the pigtail into the mating connector of the patch panel or
fiber jumper of the data center fiber plant.
To remove the Intel 100G PSM4 Optical Transceiver:
1. Disconnect the optical fiber from the module's optical receptacle connector (for receptacle modules)
or the optical fiber pigtail from the mating connector (for pigtailed modules).
2. Using the pull tab, pull the module perpendicular to the equipment faceplate until the transceiver is
free of the QSFP28 cage slot.
Table 6. E810-CQDA2T Accessories
Item Validated
Samples
Available
from Intel
Notes
Intel
®
Silicon Photonics 100G PSM4 QSFP28
Optical Transceiver Receptacle, Version LH
Yes Yes Product code SPTSBP2PMCLH / MM 99AXT2
Requires separate LC fiber breakout cable (see
Section 2.5.1).
Intel
®
Silicon Photonics 100G PSM4 QSFP28
Optical Transceiver, Version LH With 1.8m LC
Breakout Fiber Pigtail
No Yes Product code SPTSBP3PCCLH002 / MM 99AXT3
Intel
®
Silicon Photonics 100G PSM4 QSFP28
Optical Transceiver, Version LH With 2.7m LC
Breakout Fiber Pigtail
Yes No Product code SPTSBP3PCCLH003 / MM 99AXT8
Intel
®
Ethernet SFP+ LR Optics See Notes
column
No Product code E10GSFPLR
Intel has verified interoperability with 10 GbE Intel
®
Ethernet SFP+ LR Optics.
LC Fiber Breakout Cable See Notes
column
No Intel has verified functionality with:
•FS 8FMTPLCSMF
• Hitachi 61538-12
Direct Attach Cable (DAC) See Notes
column
No Intel has verified functionality with:
• Amphenol SF-NDAQGF100G-003M
• Cisco QSFP-4SFP25G-CU2M
Notes about PSM4 transceivers:
• Parallel Single Mode 4-Channel (PSM4) is a type of single-mode transceiver using parallel fiber designs consisting of four
channels.
• The E810-CQDA2T adapter can connect two PSM4 transceivers and provide a total of eight 10 GbE signals via an MPO breakout
cable. The Intel PSM4 transceiver has gone through extensive Intel qualification and is certified for use with the E810-CQDA2T.
